JCV3 Cassette Vehicle
Multi-Purpose Carrier for Various Applications
The JACON Cassette Vehicle is a robust multi-purpose vehicle designed and built to carry various cassettes to a number of different applications.
Key features
- Four Person Front Cabin
- 6T Payload
- Combination Leaf & Airbag Suspension
- Quick cassette interchange
- FOPS/ROPS Cabin
- Easily Maintainable
- 4WD/4WS
- Safety
Benefits
- Multi-Purpose; 9 cassettes available
- Suspension allows for steady rear load
- Durable and built to last harsh underground conditions
- Easy manoeuvrability and short turning radius
- Increased productivity
- Cost effective solution
- Safer worksite
Description
Multi-Purpose Carrier for Various Applications
You must be logged in to post a review.
Related products
-
Transmix 6000 Shotcrete Combo
Read moreThe unit is set up for a “one man” operation – the bowl automatically discharges to keep the hopper filled...
View product -
JWJ6 Waterjet 12,000
Read moreThe JACON Waterjet 12,000L has been purpose built to provide a range of applications to the mine in order to...
View product -
JSV3-PV8 Service Vehicle
Read moreThe JACON Personnel & Service Vehicle is a unique and reliable utility vehicle, with capabilities of transporting 8 personnel underground...
View product -
Transmix 5000 Shotcrete Combo
Read moreThe unit is set up for a “one man” operation – the bowl automatically discharges to keep the hopper filled...
View product
Specifications
Engine
| Engine | 168kW @ 2200 RPM |
|---|
Carrying Capacity
| Carrying Capacity | 6,000 kgs |
|---|
Cassette Options
| Fuel Tanker | Explosives Carrier | Emulsion Module |
|---|---|---|
| Sludge Suction | 3T Scissorlift | Service Module |
| Lube Carrier | Water Tanker | Material Carrier |
Drive
| Diesel-Hydraulic Drive | Standard |
|---|---|
| Electric-Hydraulic Drive | X |
| Diesel & Electric Drive | X |
Dimensions
| Length | 7324 |
|---|---|
| Width | 2260 |
| Height | 2710 |
| Total Weight (Empty) | 6,000 kgs |
| Total Weight (Full Loaded) | 12,000 kgs |
| Steering Type | 4WD/4WS |
Turning Radius
| Inner | R3120 |
|---|---|
| Outer | R6700 |
Drive & Gradeability
| Unloaded = 6T | Loaded = 12T | |
| Max Speed @ 0% Grade | 58km/h | 56km/h |
| Max Speed @ 5% Grade | 46km/h | 32km/h |
| Max Speed @ 10% Grade | 35km/h | 23km/h |
| Max Speed @ 15% Grade | 37km/h | 18km/h |
| Max Speed @ 20% Grade | 24km/h | |
| Max Speed @ 25% Grade | 20km/h | |
| Max Grade Climb Ability | 35% @ 15km/h | 16% @ 16km/h |
