T75 Truck Mounted Concrete Pump
Jacon’s enhanced range of concrete pumps vary in output capabilities to provide a variety of concrete pumping services such as footings, concrete slabs, blockfilling, footpaths and driveways.
Key features
- Water Pump with Stainless Steel Water Tanks
- High Pressure Water Pump with Lance
- Air Blow Out System
- Spot Light on Hopper
- 4 Channel Remote Control
- Variable Displacement Piston Pump
- Independent Hydraulic Circuit for Auxillaries
- Mounting to Truck Chassis
- Standard LED Road Lighting
- Drop Down Doors on Side of Unit
You must be logged in to post a review.
Related products
-
T60 Truck Mounted Concrete Pump
Read moreJacon’s enhanced range of concrete pumps vary in output capabilities to provide a variety of concrete pumping services such as...
View product -
T125 Truck Mounted Concrete Pump
Read moreJacon's enhanced range of concrete pumps vary in output capabilities to provide a variety of concrete pumping services such as...
View product -
S100 Trailer Mounted Concrete Pump
Read moreJacon's enhanced range of concrete pumps vary in output capabilities to provide a variety of concrete pumping services such as...
View product -
Spraymaster
Read moreThe Spraymaster has been purpose built for trouble free shotcreting operations. With a maximum pumping output of 45m3/hr, (30m3/hr whilst...
View product
Specifications
| Pump | 180mm cylinders with 1486mm stroke |
|---|
POWER UNIT
| PTO | Standard |
|---|---|
| 6 Cylinder Engine | N/A |
| Hydraulic Pressure Max | 250 Bar |
|---|---|
| Rated Output | 75 Cubic Metres / Hour |
| Line Pressure Max | 70 Bar |
| Vertical Reach | 80 Metres |
| Horizontal Reach | 180 Metres |
