Tunneljet E3
4 Wheel Drive / 4 Wheel Steer
The Jacon Tunneljet E3 is a compact and large size shotcrete rig purpose-built for the toughest shotcrete applications in medium to large size tunnels.
Key features
- 16 metre reach robotic arm
- Bi-directional dual cabins
- Diesel or Electric spraying capabilities
Benefits
- Durable and built to last harsh underground conditions
- Easy manoeuvrability and short turning radius
Description
4 Wheel Drive / 4 Wheel Steer
You must be logged in to post a review.
Related products
-
MaxiJet MX3
Read moreThe Maxijet MX3 is a robust and reliable four-wheel drive, four-wheel steer machine with a hydrostatic transmission and diesel engine,...
View product -
JSV3-PV8 Service Vehicle
Read moreThe Jacon Personnel & Service Vehicle is a unique and reliable utility vehicle, with capabilities of transporting 8 personnel underground...
View product -
Transmix 6000
Read moreThe Jacon Transmixer range offers a complete and unique solution to batch mixing and transportation of concrete in mines and...
View product -
JPV3 Personnel Vehicle
Read moreThe Jacon 18 Person Personnel Vehicle is a robust personnel carrier purpose built to transport personnel into harsh underground mining...
View product
Specifications
Engine
| Engine | 137kW @ 2300rpm |
|---|
Pump Capacity
| Pump Capacity | 30m3/hour |
|---|
Drive
| Diesel-Hydraulic | Standard |
|---|---|
| Electric-Hydraulic | Optional |
Dimensions
| Length | 9550 |
|---|---|
| Width | 2444 |
| Height | 3317 |
| Total Weight (Empty) | 17,000kgs |
| Total Weight (Full Loaded) | 19,700kgs |
| Steering Type | 4WD/4WS |
Turning Radius
| Inner | R2502 |
|---|---|
| Outer | R6731 |
Drive & Gradeability
| Unloaded | Loaded | |
| Max Speed @ 0% Grade | 26.6km/h | 26.3km/h |
| Max Speed @ 5% Grade | 20.4km/h | 19.5km/h |
| Max Speed @ 10% Grade | 16.6km/h | 15.6km/h |
| Max Speed @ 15% Grade | 14.0km/h | 13.0km/h |
| Max Speed @ 20% Grade | 12.2km/h | 11.2km/h |
| Max Speed @ 25% Grade | 10.8km/h | 9.8km/h |
